Metastasis

Last Updated: March 27, 2020

Parenchymal Metastases

Figure 1: Parenchymal Metastases. In this patient with a history of lung cancer presenting with headache, there are parenchymal metastases located with the left thalamus at the gray-white junction of the right frontotemporal and right parietooccipital lobes. The lesions demonstrate predominantly low signal intensity on axial T1 pre-contrast image (top row left) but avidly enhance on post-contrast T1 image (top row right). The lesions demonstrate foci of low signal on SWI (bottom row left), suggesting associated tumoral microhemorrhage (blue arrows). The lesions demonstrate characteristic marked surrounding T2 FLAIR signal, compatible with vasogenic edema that is most conspicuous (red arrow) around the right parietal lesion.

Figure 2: A single large hemorrhagic lesion can often be a diagnostic conundrum with a large differential. This melanoma metastasis demonstrated evidence of extensive hemorrhage, with areas of T1 hyperintensity (top row left), Low T2 signal intensity and T2-hyperintense surrounding edema (top row right), and dark signal on GRE (bottom row left). Only faint enhancement was visible in the some portions of this lesion (bottom row right) when compared to the pre-contrast images (top row left), much of which may have been obscured by the tumoral hemorrhage.

Figure 3: Even without IV contrast, melanotic melanoma metastases are often bright on T1-weighted images (top row left), either because of the melanin or because of the high rate of hemorrhage of these lesions. These features also often make melanoma highly visible on SWI imaging (top row right) as black lesions. Contrast-enhanced images are still of great value in these patients (bottom row left - axial, bottom row right - coronal), often showing lesions that are otherwise not clearly visible.

Figure 4: This example of melanoma metastases demonstrates no intrinsic T1 hyperintensity (top row left). The lesions demonstrate bright enhancement on contrast-enhanced T1 sequences (top row right – axial, bottom row left – coronal). FLAIR (bottom row right) also illustrates the degree of hyperintense vasogenic edema associated with these metastases.

Pathology

  • Typically secondary to hematogenous dissemination
  • Lung, breast, melanoma, renal, and colorectal cancer represent the most common primary sites
  • Though less common, parenchymal metastases can arise in the setting of direct extension from head and neck primary tumors
  • Gross specimen appears as round, circumscribed, tan or grayish-white nodules
  • Associated features, including hemorrhage, peritumoral edema, necrosis, and mucinous material, and specific histology varies depending on the primary tumor

Clinical Features

  • Symptoms
    • Presenting symptoms are highly variable, ranging from asymptomatic (up to 75% of the time) to severe neurological deficits
    • Patients with symptoms typically present with headache, seizure, and/or focal neurological deficits
    • Specific neurological deficits directly related to the particular anatomic site of parenchymal metastases
  • Prognosis

    • Parenchymal metastatic disease overall portends a very poor outcome
    • Detection of parenchymal metastases is of critical clinical importance, as treatment strategy often drastically changes based on presence of metastatic disease

Imaging

  • General
    • Parenchymal metastases typically located at the gray-white junction
    • Majority occur within the cerebral hemispheres (80%) with the cerebellum (15%) and basal ganglia (3%) less commonly involved
    • A few primary malignancies, however, such as uterine and prostate, may show predilection for the posterior fossa
    • Parenchymal metastases may be solitary (50%), occur as two lesions (20%), or present as three or more (30%)
    • Variable size, but most are less than 1.5 cm
  • Modality specific

    • CT
      • Predominant feature of parenchymal metastases is marked surrounding vasogenic edema (white matter hypodensity abutting adjacent peripheral gray matter) and may be the only visible feature
      • Majority of metastases, if visualized, are hypo- to isodense relative to adjacent brain parenchyma
      • Metastases with high nuclear-to-cytoplasmic ratio may appear hyperdense
      • Associated hyperdense hemorrhage can be seen, particularly with melanoma, thyroid, renal cell, choriocarcinoma, and breast primaries
      • Avid enhancement is a typical feature on contrast enhanced CT
    • MR

      • T1WI
        • Metastases are usually mildly hypointense to isointense on T1WI
        • Exceptions include T1 hyperintense melanotic melanoma metastases and hemorrhagic metastases with variably increased signal depending on the age of the blood products
      • T2WI/FLAIR

        • Typically T2 hyperintense, though tumors with high nuclear-to-cytoplasmic ratio may be hypointense
        • Associated vasogenic edema appears as white matter T2/FLAIR hyperintensity surrounding metastasis
      • DWI

        • Parenchymal metastases have variable appearance on DWI, with high-cellularity tumors more likely to show restricted diffusion (high DWI/low ADC signal)
      • SWI

        • Melanoma and hemorrhagic metastases appear as low signal “blooming” on SWI
      • Contrast

        • Most parenchymal metastases demonstrate avid enhancement, particularly compared to the surrounding brain parenchyma with its intact blood-brain barrier
        • Enhancement patterns are usually solid, nodular or ring-enhancing
  • Imaging recommendations

    • Modality of choice depends on the clinical scenario and the acuity of symptoms
    • Noncontrast CT is often performed in emergent situations to evaluate for hemorrhage and to assess sequelae of mass effect
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality to completely characterize the extent of metastatic disease and to monitor for treatment response or progression
  • Mimics

    • Infectious
      • Focal nodular and ring enhancing lesions at the gray-white junction also often seen with infectious etiologies, such as cerebral abscesses and septic emboli
      • Central restricted diffusion more commonly seen with abscesses/emboli
    • Neoplastic

      • Solitary metastases in particular may be difficult to differentiate from primary CNS neoplasm such as glioblastoma
      • Glioblastoma more likely centered in deep white matter and demonstrate infiltrative appearance versus the demarcated appearance and peripheral gray-white location of metastases
    • Demyelinating

      • Demyelinating lesions, such as in multiple sclerosis, more likely to be located in deep and periventricular white matter
      • Incomplete ring enhancement classic pattern for demyelinating lesions
    • Ischemic

      • Small subacute strokes may enhance, mimicking metastatic lesion
      • Enhancement pattern with ischemia more likely to be nodular or ring enhancing

Dural/Pachymeningeal Metastases

Figure 5: Dural/Pachymeningeal Carcinomatosis. In this patient with a history of prostate cancer presenting with right facial weakness and left leg numbness, there is diffuse pachymeningeal carcinomatosis. There is extensive extra-axial thickening within the supratentorial compartment, which is intermediate in signal on T1 (top row left - red arrows) and avidly enhancing on axial (top row right) and coronal (bottom row left) post-contrast images (top row right - blue arrows, bottom row left – green arrows). More mass-like enhancing metastatic dural thickening also protrudes into the right hemisphere (top row right - yellow arrow). Axial FLAIR images (bottom row right) more clearly demonstrate the extent of surrounding hyperintense edema in the cerebral parenchyma adjacent to the larger dural metastatic lesion (bottom row right – orange arrow).

Figure 6: This dural-based metastasis along the inferior aspect of the left frontal lobe is causing a tremendous amount of hyperintense edema on this sagittal FLAIR image (top row left). Coronal (top row right), axial (bottom row left), and sagittal (bottom row right) post-contrast T1 images show this lesion to have bright enhancement and a broad dural base, a finding more typically seen with meningioma, a common mimic of metastatic disease.

Pathology

  • Typically occurs in setting of direct extension from adjacent calvarial metastases
  • Additional proposed mechanisms include retrograde seeding through valveless vertebral venous plexus, hematogenous dissemination, and lymphatic seeding
  • Most common primary sites include breast, prostate, head and neck, lung, and hematologic malignancies
  • Dural metastases appear as focal nodules or plaquelike sheets

Clinical Features

  • Symptoms
    • Range from asymptomatic, with dural metastases incidentally discovered on imaging, to those with significant neurological symptoms
    • Patients with symptoms typically present with headaches, cranial neuropathy, seizures, altered mentation, and/or visual disturbances
  • Prognosis

    • Presence of dural metastatic disease forebodes a poor prognosis with most patients eventually demonstrating disease progression
    • Disease progression typically manifests as local dural progression, distant dural spread, and leptomeningeal or intraparenchymal extension

Imaging

  • General
    • Dural metastases involve dura-arachnoid immediately subjacent to the calvarium
    • May occur from direct extension from an adjacent calvarial metastasis or hematogenous spread
    • Presence of single dural-based metastasis usually due to extension from calvarial metastatic disease
    • Most commonly, hematogenous spread to the dura presents as multiple dural enhancing lesions
  • Modality specific

    • CT
      • Limited assessment for dural-based metastases
      • Bone algorithm helpful for evaluating presence of associated calvarial metastases
    • MR

      • T1WI
        • Focal nodular or diffuse dural thickening with usually hypo- or isointense signal relative to adjacent cortex
        • Associated calvarial metastases are T1 hypointense, replacing the normal bright marrow fat
      • T2WI/FLAIR

        • Dural metastases have variable T2/FLAIR signal
        • T2/FLAIR hyperintensity of the adjacent brain parenchymal may occur with presence of vasogenic edema secondary to compression, direct invasion, or impaired venous drainage
      • DWI

        • High-cellularity metastases may show restricted diffusion (high DWI/low ADC signal)
      • Contrast

        • Foci of dural thickening demonstrate avid enhancement
        • Enhancement pattern may be smooth, nodular, or a combination of both patterns
  • Imaging recommendations

    • Modality of choice depends on the clinical scenario and on the acuity of symptoms
    • Noncontrast CT is often performed in emergent situations
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality
  • Mimics

    • Meningioma
      • Focal dural metastasis can have an essentially identical appearance to a meningioma on imaging
      • Presence of associated skull metastasis and bony erosive changes and parenchymal lesions suggest metastatic disease
      • Prior imaging very helpful to evaluate stability
    • Diffuse dura-arachnoid thickening

      • Many non-neoplastic processes can result in diffuse pachymeningeal thickening, such as chronic subdural hematomas, intracranial hypotension, autoimmune dural thickening, and infectious meningitis
      • Clinical context is often of critical importance

Leptomeningeal Metastases

Figure 7: Leptomeningeal Metastases. In this pediatric patient with a history of medulloblastoma, there is leptomeningeal thickening and enhancement noted within the right temporal sulci on axial (top row left), sagittal (top row right), and coronal (bottom row) post-contrast T1 images (arrows), compatible with leptomeningeal metastatic disease.

Figure 8: The difference between sagittal T1 pre-contrast (top row left) and post-contrast (top row right) images is striking in this patient with leptomeningeal metastatic disease, with diffuse enhancement throughout the cerebral sulci that is also visible on coronal (middle row left) and axial (middle row right) contrast-enhanced images. Scattered hyperintense sulci are also visible on FLAIR imaging (bottom row), along with reactive or metastatic thickening of the dura. Leptomeningeal metastatic disease is often very nodular, but can sometimes be smooth, as in this patient.

Pathology

  • Often occur secondary to hematogenous dissemination with breast, lung, and melanoma representing the most common primary tumor sites
  • Leptomeningeal metastases from intracranial primary tumors
    • In adults, most commonly seen with glioblastoma
    • In children, most commonly seen with medulloblastoma and other embryonal tumors
  • Multifocal tumoral deposits coating the pia mater and filling the subarachnoid spaces

Clinical Features

  • Symptoms
    • Highly variable depending on particular site of involvement
    • Typical general symptoms include headache, confusion, nausea, and vomiting
    • Cranial and spinal neuropathies are common, with diplopia, facial weakness, and hearing impairment frequent symptoms secondary to involvement of cranial nerves VI, VII, and VIII
  • Prognosis

    • Leptomeningeal metastatic disease portends a poor prognosis with an average survival of 2 to 4 months

Imaging

  • General
    • Leptomeningeal metastases involve the subarachnoid spaces and pial layer along the parenchymal surface following the gyri and sulci
    • Hydrocephalus may be present as a complication of leptomeningeal metastatic debris or secretions obstructing at the level of the arachnoid granulations
  • Modality specific

    • CT
      • Often normal but may see hydrocephalus and subtle effacement of the cerebral sulci and cisterns
      • With more pronounced involvement, can see enhancement of the cerebral sulci and cisterns
    • MR

      • T1WI
        • Often normal but may see subtle increased signal in the cerebral sulci
      • T2WI/FLAIR

        • Leptomeningeal metastases often similar in signal to CSF on T2WI
        • Unlike CSF, leptomeningeal metastases will not lose signal on FLAIR, resulting in increased signal within the sulci and cisterns
      • Contrast

        • Postcontrast T1WI will demonstrate miliary, sheet-like, or nodular enhancement of the leptomeninges resulting in enhancement of the sulci and cisterns
        • Contrast-enhanced T2 FLAIR imaging
          • Highly sensitive for detection of leptomeningeal metastases
          • Demonstrates hyperintense “enhancement” in the involved CSF spaces due to incomplete CSF signal suppression
  • Imaging recommendations

    • Modality of choice depends on clinical scenario and acuity of symptoms
    • Noncontrast CT often performed in emergent situations
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality
  • Mimics

    • Diffuse leptomeningeal thickening and enhancement
      • Many non-neoplastic processes can demonstrate diffuse leptomeningeal thickening and enhancement, such as infectious meningitis and neurosarcoidosis
      • Clinical context, history, CSF analysis are critical for distinguishing etiologies, though CSF analysis is often falsely negative for leptomeningeal disease
    • Diffusely increased signal within the subarachnoid spaces on FLAIR Many conditions can contribute to diffusely increased signal within the sulci on FLAIR, mimicking diffuse leptomeningeal metastatic disease

      • Propofol for anesthesia
      • Hyperoxygenation
      • Prior intravenous gadolinium administration
      • Subarachnoid hemorrhage
      • Infectious meningitis
    • Clinical context and history critical for distinguishing etiologies

Intraventricular/Choroid Plexus Metastases

Figure 9: Intraventricular/Choroid Plexus Metastasis. In this patient with a history of metastatic lung cancer, there is evidence of a right choroid plexus metastasis. Axial T1 image without contrast (top row left) demonstrates a right choroid plexus lesion with intermediate T1 signal (top row left - blue arrow). After administration of contrast, the lesion is much more clearly visible on axial (top row right) and coronal (bottom row) images as an avidly enhancing lesion with close association to the temporal horn choroid plexus.

Pathology

  • Typically secondary to hematogenous spread to the choroid plexus
  • Lung and renal cancer represent the most common primary sites in adults, while neuroblastoma, Wilms tumor, and retinoblastoma are the most common etiologies in children

Clinical Features

  • Intraventricular metastases are relatively uncommon, representing only 0.9 to 4.6% of cerebral metastases
  • Symptoms
    • Intraventricular neoplasms in general result in varied presentations based on particular location
    • Nausea, vomiting, and headache are more likely in the setting of hydrocephalus and elevated intracranial pressure
  • Prognosis

    • Presence of intraventricular metastatic disease generally indicates a poor prognosis

Imaging

  • General
    • Mass-like enlargement of the choroid plexus
    • Involvement is most common in the lateral ventricle and second most common in the third ventricle
    • Choroid plexus metastases are often hemorrhagic
  • Modality specific

    • CT
      • Iso- to hyperdense enlargement of the choroid plexus
      • Avid, heterogeneous enhancement post-contrast
    • MR

      • T1WI
        • Usually hypointense on T1WI
        • Variable signal with hemorrhagic metastases
      • T2WI/FLAIR

        • Typically T2/FLAIR hyperintense
        • May have edema of the adjacent brain parenchyma
      • SWI

        • Hemorrhagic metastases demonstrate hypointense signal on SWI
      • Contrast

        • Avid, heterogenous enhancement
  • Imaging recommendations

    • Modality of choice depends on the clinical scenario and on the acuity of symptoms
    • Noncontrast CT is often performed in emergent situations
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality
  • Mimics

    • Choroid plexus/intraventricular metastases are often indistinguishable from intraventricular meningiomas and from primary choroid plexus papillomas and carcinomas
    • Age of the patient and presence of a known primary malignancy should influence concern for metastatic disease
    • Prior imaging very helpful for documenting stability of non-metastatic lesions

Pineal Metastases

Figure 10: Pineal Metastasis. In this patient with a history of melanoma presenting with headache, there is evidence of right frontal parenchymal and pineal metastases. Non-contrasted T1 axial images demonstrate the hyperintense right frontal metastasis (top row left – red arrow) and the hyperintense pineal metastasis (top row right – blue arrow). The pineal metastasis is also visible on sagittal T1 image (middle row left – yellow arrow). The high T1 signal is a common feature of melanoma metastases. Axial T1 post-contrast image (middle row right) demonstrates these right frontal parenchymal (green) and pineal (orange) lesions as having additional hyperintense enhancement. On axial T2 FLAIR image (bottom row), the pineal lesion demonstrates low signal (white arrow), while the right frontal parenchymal lesion demonstrates characteristic associated subcortical vasogenic edema (teal arrow).

Pathology

  • Occur most commonly from hematogenous spread of extracranial malignancies, with lung (most common), breast, renal and GI representing the most common primary sites

Clinical Features

  • Symptoms
    • Pineal neoplasms in general result in symptoms arising from mass effect on nearby structures
    • Compression of the tectal plate can result in Parinaud syndrome (vertical gaze paralysis, pupillary dysfunction, blepharospasm)
    • Obstruction of cerebral aqueduct contributes to hydrocephalus and increased intracranial pressure with headache, nausea, and vomiting

Imaging

  • General
    • Mass involving the pineal gland
    • Often solitary without additional intracranial metastases
    • Variable appearance on CT and MR, but likely to demonstrate avid enhancement
    • Commonly see associated obstructive hydrocephalus
  • Imaging recommendations

    • Modality of choice depends on clinical scenario and acuity of symptoms
    • Noncontrast CT often performed in emergent situations
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality to completely characterize the extent of metastatic disease and to monitor for treatment response or progression
  • Mimics

    • Pineal metastases having similar imaging characteristics of other primary pineal neoplasms (for example, pineoblastoma or pineocytoma), making clinical history of critical importance

Pituitary Metastases

Figure 11: Pituitary Infundibulum Metastasis. In this patient with a history of breast cancer, there is evidence of a pituitary infundibulum metastasis. Mass-like enlargement of the pituitary infundibulum is noted on pre-contrast axial T1 image (top row left - blue arrow). This lesion also demonstrates avid enhancement typical of metastatic disease on post-contrast T1 axial (top row right – red arrow) and coronal (bottom row left – yellow arrow) images. This lesion demonstrates mild FLAIR hyperintensity (bottom row right – green arrow), but a metastatic lesion in this location has less continuity with surrounding parenchyma which often renders the associated vasogenic edema less conspicuous.

Pathology

  • Usually occur secondary to hematogenous spread of extracranial primary malignancies, with breast and lung representing the most common primary sites

Clinical Features

  • Symptoms
    • Often patients present with diabetes insipidus due to predilection for metastases to involve the posterior pituitary lobe and infundibulum
    • Anterior hypopituitarism may also occur, though less likely
    • Visual deficits may be seen secondary to compression of the optic chiasm

Imaging

  • General
    • Sellar-based mass with variable associated mass effect on adjacent supra- or parasellar structures such as the optic chiasm, and with bony changes
    • Predilection for local invasion and rapid growth
  • Modality specific

    • CT
      • May see erosive bony changes of the sella turcica
    • MR

      • Sella-based mass with usually avid enhancement
      • May have thickening and enhancement of the infundibulum
      • Often have loss of normal T1 bright spot of the posterior pituitary
      • May see cavernous sinus invasion
  • Imaging recommendations

    • Modality of choice depends on clinical scenario and acuity of symptoms
    • Noncontrast CT often performed in emergent situations
    • If non-emergent, MR without and with intravenous contrast is the preferred imaging modality
    • Dynamic sella protocol MRI may be helpful
  • Mimics

    • Pituitary and infundibular metastases can be difficult to distinguish from other primary neoplastic processes such as a macroadenoma, and non-neoplastic processes such sarcoidosis and lymphocytic hypophysitis
    • Presence of diabetes insipidus and rapid growth are more suggestive of metastasis
    • Clinical context and presence of known systemic malignancy is of critical importance

Contributor: Benjamin Gray, MD

DOI: https://doi.org/10.18791/nsatlas.v1.03.01.29

References

Ahn JY, Chung YS, Kwon SO, et al. Isolated pineal region metastasis of small cell lung cancer. J Clin Neurosci 2005;12:691–693 (10.1016/j.jocn.2004.09.010).

Barajas RF, Jr, Cha S. Metastasis in adult brain tumors. Neuroimaging Clin N Am 2016;26:601–620 (10.1016/j.nic.2016.06.008).

Barajas RF, Jr, Cha S. Imaging diagnosis of brain metastasis. Prog Neurol Surg 2012;25:55–73 (10.1159/000331174).

Bekaert L, Emery E, Levallet G, et al. Histopathologic diagnosis of brain metastases: current trends in management and future considerations. Brain Tumor Pathol 2017;34:8–19 (10.1007/s10014-016-0275-3).

Fink KR, Fink JR. Imaging of brain metastases. Surg Neurol Int 2013;4(Suppl 4):S209–S219 (10.4103/2152-7806.111298).

Gavrilovic IT, Posner JB. Brain metastases: epidemiology and pathophysiology. J Neurooncol 2005;75:5–14 (10.1007/s11060-004-8093-6).

Healy JF, Rosenkrantz H. Intraventricular metastases demonstrated by cranial computed tomography. Radiology 1980;136:124 (10.1148/radiology.136.1.6247741).

Koshimoto Y, Maeda M, Naiki H, et al. MR of pituitary metastasis in a patient with diabetes insipidus. AJNR Am J Neuroradiol 1995;16(4 Suppl):971–974.

Li J, Wang P, Wang B. Unique case report of pineal gland metastasis from bladder carcinoma. Medicine (Baltimore) 2016;95:e3622 (10.1097/MD.0000000000003622).

Morris JM, Miller GM. Increased signal in the subarachnoid space on fluid-attenuated inversion recovery imaging associated with the clearance dynamics of gadolinium chelate: a potential diagnostic pitfall. AJNR Am J Neuroradiol 2007;28:1964–1967 (10.3174/ajnr.A0694).

Nayak L, Abrey LE, Iwamoto FM. Intracranial dural metastases. Cancer 2009;115:1947–1953 (10.1002/cncr.24203).

Osborn AG, Hedlund GL, Salzman KL. Osborn’s Brain: Imaging, Pathology, and Anatomy. Elsevier, Philadelphia, PA. 2018.

Sava I, Sava A, Şapte E, et al. Intraventricular metastatic clear cell renal carcinoma. Rom J Morphol Embryol 2013;54:447–450.

Schubiger O, Haller D. Metastases to the pituitary—hypothalamic axis. An MR study of 7 symptomatic patients. Neuroradiology 1992;34:131–134.

Stuckey SL, Goh TD, Heffernan T, et al. Hyperintensity in the subarachnoid space on FLAIR MRI. AJRAm J Roentgenol 2007;189:913–921 (10.2214/AJR.07.2424).

Wang N, Bertalan MS, Brastianos PK. Leptomeningeal metastasis from systemic cancer: review and update on management. Cancer 2018;124:21–35 (10.1002/cncr.30911).

Please login to post a comment.

Top
